Hobbywing EZRUN 4268SL Sensorless Brushless Motor 2600kV 30402750

The Hobbywing EZRUN 4268SL 2600kV Sensorless Brushless Motor is designed for powerful 1/8 scale applications including buggies, truggies, SCTs and on-road RC vehicles. Built with a 4-pole rotor and CNC machined aluminium housing, it delivers fast acceleration, high torque and stable output. Ideal when paired with the Hobbywing EZRUN MAX8 ESC.

Features

• 4-pole rotor for enhanced torque and acceleration response
• Advanced thermal control technology ensures less heat and up to 90% efficiency
• CNC machined aluminium housing with high-purity copper windings
• Durable alloy steel output shaft and high-precision bearings
• Partially rebuildable design allows for routine maintenance and extended lifespan
• Optimally matched with the Hobbywing EZRUN MAX8 ESC

Specifications

• Poles: 4
• KV Rating (No-load): 2600kV
• Internal Resistance: 0.0052Ω
• No-load Current: 4.2A
• Max Output Power: 3000W
• Current at Max Output: 120A
• Dimensions: 42mm diameter x 68mm length
• Shaft Dimensions: 5mm diameter x 18.5mm length
• Battery Compatibility: 2–4S LiPo
• Weight: 343g
• Applications: 1/8 Buggies, Touring Cars, SCTs

Includes

• Hobbywing EZRUN 4268SL 2600kV Sensorless Brushless Motor

Important Notes

• Use M3 or M4 mounting screws no longer than 10mm (mounting hole depth is 8mm)
• Motor wires A/B/C can be connected in any order; swap any two if motor runs in reverse
• Ensure all connections are secure before powering on
