SkyRC T100 100W Dual Balance Charger LiPo NiMH XT60 SK-100162

The SkyRC T100 is a dual-channel AC balance charger for RC batteries, allowing two packs with different supported chemistries and configurations to be charged independently at the same time with up to 50W and 5A available per channel

Features

• Two fully independent charging channels allow two batteries to be charged simultaneously
• Each channel provides up to 50W charging power for a combined maximum of 100W
• Maximum charge current of 5A per channel
• Supports LiPo, LiHV, LiFe, LiIon, NiMH, NiCd and Pb battery chemistries
• Each channel can charge a different supported battery chemistry or configuration at the same time
• Integrated XT60 female output connectors simplify connection of XT60-equipped batteries and charge leads
• Front-mounted XH balance ports provide convenient lithium battery balance connections
• 300mA per cell balance current
• AGM and cold-charge modes are available for compatible Pb batteries
• AC 100-240V input allows direct mains operation without a separate DC power supply
• Two-line backlit LCD display provides charging information and menu access
• Stores up to 10 different charge profiles
• Compact bench footprint suits home workshops and RC pit areas

Specifications

• Brand: SkyRC
• Model: T100
• Product Type: Dual Battery Balance Charger
• Part Number: SK-100162
• Input Voltage: AC 100-240V
• Charge Power: 50W x 2
• Total Maximum Charge Power: 100W
• Charge Current: 0.1A to 5.0A per channel
• Balance Current: Up to 300mA per cell
• Lithium Balance Port: XH 2S to 4S
• Main Output Connector: XT60 Female
• LiPo Cell Support: 2S to 4S
• LiHV Cell Support: 2S to 4S
• LiFe Cell Support: 2S to 4S
• LiIon Cell Support: 2S to 4S
• NiMH Cell Support: 6 to 8 cells
• NiCd Cell Support: 6 to 8 cells
• Pb Battery Support: 6V or 12V
• Battery Capacity Range: 100 to 50000mAh
• Display: 2 x 16 Character Backlit LCD
• Case Material: Plastic
• Dimensions: 100 x 90 x 127 mm
• Weight: Approximately 500 g

Includes

• 1 x SkyRC T100 Dual Balance Charger
• 1 x AC power lead where supplied for the regional version
• 1 x Instruction manual

FAQ

Can the SkyRC T100 charge two different batteries at the same time? Yes, the T100 uses two independent charging circuits, so each channel can charge a different supported battery chemistry, capacity or cell configuration at the same time

How much charging power does each channel provide? Each T100 channel provides up to 50W and a maximum charge current of 5A, giving the charger a combined maximum output of 100W

Can the SkyRC T100 charge 6S LiPo batteries? No, the T100 supports LiPo, LiHV, LiFe and LiIon batteries from 2S to 4S only

Does the T100 need a separate power supply? No, the T100 operates directly from AC 100-240V mains power and does not require a separate DC power supply

Does the T100 have XT60 outputs? Yes, each channel has an integrated XT60 female connector along with an XH balance port for compatible lithium batteries

Important Notes

• Maximum charging power is 50W per channel rather than 100W per channel
• Maximum lithium battery support is 4S
• Use the correct battery chemistry, cell count and charge current settings before starting a charge
• Lithium batteries should be connected to the appropriate balance port when balance charging
• Charging leads or connector adaptors may be required for batteries that do not use XT60 connectors
• Never leave batteries unattended while charging
• Use an appropriate fire-resistant charging location and follow the battery manufacturer's safety instructions
