Venom 7.2V 5000mAh 6-Cell RC NiMH Stick Battery UNI 2.0 VEN-1548
Couldn't load pickup availability
The Venom VEN-1548 is a 7.2V 5000mAh 6-cell NiMH stick battery designed for compatible RC cars, trucks, buggies and boats, with a UNI 2.0 connector system providing flexible connection options for popular RC plugs.
Features
- 5000mAh Capacity: High-capacity rechargeable NiMH pack for compatible RC surface and marine applications
- 7.2V 6-Cell Configuration: Designed for RC vehicles requiring a standard six-cell 7.2V NiMH battery
- Stick Pack Design: Measures approximately 137 x 45 x 23.9mm for compatible RC battery compartments
- UNI 2.0 Plug System: Uses an XT60 base connection with adaptor compatibility for popular RC connector types
- Multiple Connector Options: Compatible with XT60, Traxxas Legacy, Deans/T-Style and EC3 using the appropriate UNI 2.0 configuration
- 12 AWG Wiring: Uses soft and flexible low-resistance silicone wire
- 1C Charge Rate: Specified for charging at up to 5A with a suitable NiMH charger
- 36Wh Energy Capacity: Combines 7.2V nominal voltage with 5000mAh capacity
Specifications
- Brand: Venom
- Product Type: RC NiMH battery
- Battery Chemistry: Nickel Metal Hydride (NiMH)
- Battery Style: Stick pack
- Capacity: 5000mAh
- Voltage: 7.2V
- Cell Count: 6 cells
- Cell Configuration: 6-cell
- Charge Rate: 1C / 5A
- Energy: 36Wh
- Connector System: Venom UNI 2.0 Land Plug System
- Base Connector: XT60
- Connector Compatibility: XT60, Traxxas Legacy, Deans/T-Style and EC3
- Wire Gauge: 12 AWG
- Wire Type: Soft flexible low-resistance silicone wire
- Dimensions: 137 x 45 x 23.9mm
- Weight: 408g
- Manufacturer Part Number: 1548
- SKU: VEN-1548
- Barcode / UPC: 873067007738
Includes
- 1 x Venom 7.2V 5000mAh 6-cell NiMH stick battery with UNI 2.0 connector system
FAQ
What RC vehicles can use the Venom VEN-1548 battery? The Venom VEN-1548 is suitable for compatible RC cars, trucks, buggies and boats that support a 7.2V six-cell NiMH battery. It is commonly used with 1/10 scale brushed RC applications, but battery dimensions, voltage and connector compatibility should be checked before ordering.
What connectors does the Venom VEN-1548 support? The Venom UNI 2.0 system uses an XT60 base connector and supports Traxxas Legacy, Deans/T-Style and EC3 connections using the appropriate UNI 2.0 adaptors.
What size is the Venom VEN-1548 battery? The VEN-1548 measures approximately 137 x 45 x 23.9mm. OZRC recommends checking these dimensions against the vehicle's battery compartment before ordering.
What charger does the Venom VEN-1548 require? The VEN-1548 requires a charger suitable for 7.2V NiMH battery packs. The specified charge rate is 1C or 5A.
Important Notes
- Use only a charger and charging mode suitable for NiMH batteries
- Specified charge rate is 1C / 5A
- Confirm the RC vehicle supports a 7.2V six-cell NiMH battery before use
- Check the 137 x 45 x 23.9mm dimensions against the available battery compartment before ordering
- Confirm connector compatibility before connecting the battery
- Allow the battery to cool before recharging
