Hobbywing XeRun Justock Handout 17.5T 2600KV Sensored Motor 30408017
Couldn't load pickup availability
The Hobbywing XeRun Justock Handout 17.5T is a 2600KV sensored brushless motor developed for controlled 1/10 stock-class racing, using fixed timing and tightly controlled manufacturing to provide consistent performance between motors
Features
- Designed specifically for fair and consistent 1/10 stock-class racing
- 17.5T specification with a 2600KV rating
- Fixed mechanical timing supports controlled spec-class use
- Sensored brushless design provides smooth and precise throttle response
- Dual sensor ports provide flexible wiring options for different chassis layouts
- High-precision four-stage rotor helps reduce cogging torque and improve low-speed linearity
- Independent Hall detection magnetic ring supports accurate sensor positioning
- Asymmetrical front and rear precision bearings are used to reduce resistance and support smooth operation
- High-temperature 200°C winding wire and heat-resistant rotor materials support durability
- Optimised stator and rotor design improves operating efficiency compared with the Justock G2.1 generation
- Compact 48.5 mm motor length helps reduce vehicle weight and assists chassis weight distribution
Specifications
- Brand: Hobbywing
- Series: XeRun Justock Handout
- Product Type: Sensored Brushless Motor
- Part Number: 30408017
- SKU: HW30408017
- Barcode: 6938994419918
- Scale: 1/10
- Motor Turn: 17.5T
- KV Rating: 2600KV
- Motor Type: Brushless
- Sensor Type: Sensored
- Pole Count: 4
- Supported LiPo Cells: 2S to 3S
- No-Load Current: 2.2A
- Internal Resistance: 0.0244 ohm
- Motor Diameter: 36 mm
- Motor Length: 48.5 mm
- Shaft Diameter: 3.175 mm
- Shaft Length: 12.4 mm
- Weight: 148.5 g
- Front Bearing: D11 x D5 x T5 mm
- Rear Bearing: D8 x D3 x T4 mm
- Timing: Fixed
- Primary Application: 1/10 Stock Class Racing
Includes
- 1 x Hobbywing XeRun Justock Handout 17.5T 2600KV sensored brushless motor
FAQ
Is the Hobbywing Justock Handout 17.5T motor timing adjustable? No, HW30408017 uses fixed timing and is specifically designed around controlled stock-class racing where consistent motor performance is important
Is the HW30408017 motor sensored? Yes, the Justock Handout 17.5T is a sensored brushless motor and uses dual sensor ports to provide more flexible sensor-wire routing
What battery voltage can the 17.5T Justock Handout motor use? Hobbywing specifies the 2600KV 17.5T motor for 2S to 3S LiPo operation, although OZRC recommends following the voltage limits and class rules for the ESC and race category being used
What ESC is recommended for the Justock Handout motor? Hobbywing lists the XeRun XR10 Justock G3 Handout ESC as the recommended matching speed controller for the Justock Handout motor series
Important Notes
- Motor timing is fixed and not designed for mechanical timing adjustment
- Confirm your race organisation permits this specific motor before entering a controlled stock or handout class
- Hobbywing recommends 3 mm motor mounting screws and notes that screws shorter than 8 mm should generally be used to avoid internal motor damage
- ESC, sensor wire, pinion gear, battery and installation hardware are not confirmed as included
- Confirm ESC voltage limits and gearing before operating the motor
