Hobbywing Xerun XD10 Pro 1/10 Drift Brushless ESC Black 30112614

The Hobbywing Xerun XD10 Pro Black is a 1/10 scale drift brushless ESC designed for RC drift drivers needing smooth throttle control, precise braking adjustment and reliable 2S LiPo power delivery.

This XD10 Pro drift speed controller combines sensored brushless operation, drift-optimised programming, adjustable high-voltage BEC output and Hobbywing programming support for competitive drift chassis setups.

Features

• Designed specifically for 1/10 scale RC drift car applications
• 100A continuous current and 800A peak current support high-performance drift setups
• Sensored and sensorless brushless motor support provides flexible motor compatibility
• Drift-optimised programmable parameters help refine throttle and brake feel
• 48K ultra-high drive frequency and 24K ultra-high brake frequency support smooth control response
• Adjustable 5V to 7.4V switch-mode BEC allows tuning for compatible servos and receiver setups
• Reverse polarity protection helps reduce the risk of ESC damage from incorrect battery connection
• Separate programming port allows easier setup with compatible Hobbywing programming devices
• Supports Hobbywing OTA Programmer and compatible LCD program boxes for tuning and firmware updates
• Real-time data logging is supported when used with a compatible Hobbywing OTA module
• Pre-installed 30 x 30 x 10mm cooling fan is powered by the ESC BEC
• Ultra-soft 13AWG silicone wires support flexible installation in drift chassis layouts
• Black Stealth finish suits clean drift builds and low-profile electronics layouts

Specifications

• Brand: Hobbywing
• Model: Xerun XD10 Pro Black
• SKU / Part Number: HW30112614 / 30112614
• Product Type: Electronic speed controller
• Scale: 1/10
• Application: RC drift car
• Motor Type: Sensored and sensorless brushless motors
• Input Voltage: 2S LiPo
• Continuous Current: 100A
• Peak Current: 800A
• BEC Output: 5V to 7.4V adjustable
• BEC Continuous Current: 5A switch-mode
• Motor Limit: 2S LiPo brushless motor with 8.5T or higher turn count
• Input Wires: Black 13AWG 250mm x 2
• Output Wires: Black 13AWG 250mm x 3
• Input Connector: Not included
• Output Connectors: 3.5mm male plugs
• Fan Size: 30 x 30 x 10mm
• Fan Voltage Range: 5V to 7.4V
• Fan Power Source: Powered by BEC
• Programming: SET button, LED program box, LCD Program Box Pro and OTA Programmer support
• Program Port: Separate program port
• Firmware Upgrade: Supported
• Waterproof: No
• Dimensions: 40.7 x 35.0 x 32.0mm with fan
• Weight: 95g with wires
• Colour: Black

Includes

• 1 x Hobbywing Xerun XD10 Pro Black drift brushless ESC
• 1 x Pre-installed cooling fan
• 1 x Set of factory-installed ESC wires
• 1 x Factory accessory set
• 1 x Instruction manual

FAQ

Does the Hobbywing XD10 Pro Black suit normal touring or buggy use? The Hobbywing XD10 Pro Black is designed specifically for 1/10 scale drift cars, so OZRC recommends choosing a different ESC for touring, buggy or general off-road racing unless the setup requirements match the XD10 Pro specifications.

Does this ESC include a battery connector? No. Hobbywing lists the XD10 Pro with no input connector fitted, so a suitable battery connector must be soldered separately.

What battery does the XD10 Pro use? The Hobbywing XD10 Pro is designed for 2S LiPo battery use.

Is the Hobbywing XD10 Pro waterproof? No. Hobbywing lists the XD10 Pro as not waterproof, so it should be kept away from water and wet driving conditions.

Important Notes

• Use suitable ESC settings for your motor, gearing, battery, servo and driving conditions.
• Incorrect timing, boost, turbo, gearing or brake settings may overheat or damage the ESC or motor.
• Check ESC, motor and capacitor temperatures during setup and after changing settings.
• Battery connector is not included and must be soldered before use.
• Use only with suitable 2S LiPo batteries and brushless motors rated for the ESC setup.
• This ESC is not waterproof and should not be used in wet conditions.
